Product introduction
This 2.4GHz directional reader RLT2606, operating at 2.45GHz (ISM band), uses a high-end RF SOC chip that incorporates advanced anti-collision algorithms and strong anti-interference features, it can perform automatic identification, tracking, regional positioning, collection and other functions without manual participation;The 2.4GHz directional reader RLT2606 is very suitable RFID reader for outdoor applications and can be widely used in logistics tracking, commodity inventory, goods sorting, vehicle management, personnel management, asset management, medical system, cold chain management, power monitoring and production process control, etc.
Product Features
*Far recognition distance , effective visual recognition distance up to 200 meters;
* Strong multi-tag recognition capacity, up to 200 sheets / second;
* Up to 2000 tags data cache capacity, data will not be lost when the power is off;
* Rich wired data interface, support 10M/100M adaptive network port, RS232, RS485,Weigand;(standard)
* Wireless data interface, supports 4G, WIFI data transmission; (optional)
* AC100V-240V~0.6A,50-60HZ Power supply
* Operation LED indication
* Support online and offline working modes such as command, auto, trigger reading;
* Compact and elegant appearance, easy to install;
* Demo software and SDK development kit supported;
Specifications
General parameters | |
Product Dimensions | 220*220*75mm |
Package Dimensions | 240*240*90mm |
Weight | Net 2.5Kg,Gross weight3.0kg(with package) |
Operating Temperature | -25℃～+60℃ |
Storage Temperature | -40℃～+80℃ |
Humidity | 5％～95％(non-condensing) |
Power supply | AC100V-240V~0.6A,50-60HZ |
Performance Indexes | |
Operating Frequency | 2.4GHz～2.4835GHz |
Operation mode | Active/passive operating mode |
Sensitivity | -93dBm±1.0dB （Adjustable） |
Input Power(Max) | 100W |
Reading distance | 0-150m |
IP rating | IP67 |
Antenna Gain | 15dBi |
VSWR | <1.4 |
Horizontal Beam-wide | 40° |
Vertical Beam-wide | 35° |
Input impedance | 50Ω |
External interfaces | |
Communication Interfaces | RS232/ RS485 ,10/100M Ethernet ，WG26、WG34，relays input& output |
Optional Interfaces | 4G,WIFI |
Port and Pin definition
