RLT-2605D 2.4G FIXED RFID READER

This 2.4GHz directional reader RLT2605, operating at 2.45GHz (ISM band), uses a high-end RF SOC chip that incorporates advanced anti-collision algorithms and strong anti-interference features, it can perform automatic identification, tracking, regional positioning, collection and other functions without manual participation
Place of Origin CHINA
Brand Name REYLINK
Model Number RLT-2605D
Minimum Order 1 Piece
Packaging Details Standard Export Carton, Foam and Protective Film
Delivery Time 5~7 work days
Payment Terms T/T, Western Union, Paypal
Contact Whatsapp
Get Best Price
Product profileDownload
This 2.4GHz directional reader RLT2605, operating at 2.45GHz (ISM band), uses a high-end RF SOC chip that incorporates advanced anti-collision algorithms and strong anti interference features,   it can perform automatic identification, tracking, regional positioning, collection and other functions without manual participation;

The 2.4GHz directional reader RLT2605 is very suitable RFID reader for outdoor applications and can be widely used in logistics tracking, commodity inventory, goods sorting, vehicle management, personnel management, asset management, medical system, cold chain management, power monitoring and production process control, etc.


Features

1.Far recognition distance , effective visual recognition distance up to 200 meters;

2. Strong multi-tag recognition capacity, up to 200 sheets / second;

3.Up to 2000 tags data cache capacity, data will not be lost when the power is off;

4. Rich wired data interface, support 10M/100M adaptive network port, RS232, RS485, Weigand; (standard)

5.Wireless data interface, supports 4G, WIFI data transmission; (optional)

6.Wide voltage power supply, DC 5V to 18V;

7.Support online and offline working modes such as command, auto, trigger reading;

8.Compact and elegant appearance, easy to install;

9.Demo software and SDK development kit supported;

General parameters

Product Dimensions

320mm×200mm×100mm

Package Dimensions

370mm×250mm×150mm

Weight

Net 2Kg,Gross weight 2.5kg(with package)

Operating Temperature

-25℃+60

Storage Temperature

-40℃+80

Humidity

5%~95(non-condensing)

Power supply

DC-5V~2A(can be customized between 5V-18V)

Performance Indexes

Operating Frequency

2.4GHz2.4835GHz

Operation mode

Active/passive operating mode

Sensitivity

-93dBm±1.0dB Adjustable

Operation current

<200mA/DC12V

Reading distance

0-150m

IP rating

IP65

Output power

20dBmAdjustable

VSWR

<1.5

Horizontal Beam-wide

30°

Vertical Beam-wide

25°

Input impedance

50Ω

External interfaces


Communication Interfaces

RS232/ RS485 ,10/100M Ethernet ,WG26WG34

Optional Interfaces

4G,WIFIrelays



Product application

1.Vehicle management:monitoring and managing autos and containers
2.Customs management:great speed up the customs’ process
3.Logistics management:parcels and whale house management
4.Access control:including car access and personal access
5.Production line management:monitoring products from end to end

6.Asset management:dramatically improThe 2.4GHz directional reader RLT2605 is very suitable RFID reader for outdoor applications and can be widely used in logistics tracking, commodity inventory, goods sorting, vehicle
